数字人工程解读（五）：Ditto 源码：把 Talking Head 做成实时流水线

antgroup/ditto-talkinghead 是 Ant Group 开源的实时 Talking Head 生成项目，对应论文 Ditto: Motion-Space Diffusion for Controllable Realtime Talking Head Synthesis。仓库主分支面向推理，训练代码放在 train 分支。#Ditto GitHub #Ditto Paper

它的输入是一张人脸图或一段 source video，再加一段音频；输出是一段跟随音频说话的头像视频。README 给出的推理命令显示，用户主要通过 inference.py 传入 --data_root、--cfg_pkl、--audio_path、--source_path 和 --output_path。

图 1：仓库 example/image.png 中的示例 source image。推理时它会先经过人脸检测、裁剪、关键点与 appearance feature 提取，再进入后续驱动流程。

读模型仓库时，使用路径会暴露真实工程边界：依赖什么硬件、权重如何组织、入口参数是什么、训练和推理是否在同一个分支。

安装与模型下载

README 推荐用 environment.yaml 创建 conda 环境；如果不用 conda，则要自行准备 PyTorch、CUDA、cuDNN、TensorRT、librosa、OpenCV、cuda-python 和 ffmpeg 等依赖。README 标注测试环境为 CentOS 7.2、NVIDIA A100、Python 3.10、PyTorch 2.5.1、CUDA 12.1、TensorRT 8.6.1。#Ditto GitHub

conda env create -f environment.yaml
conda activate ditto

权重从 HuggingFace 下载到本地 checkpoints 目录。README 中列出的权重形态包括 ditto_cfg、ditto_onnx、ditto_trt_Ampere_Plus 和 ditto_pytorch。本次阅读中 HuggingFace 页面访问超时，因此只采用 README 中能核实到的说明。#Ditto HuggingFace

推理命令

README 的推理命令本质上是在告诉 inference.py 三件事：模型在哪里、输入素材在哪里、结果写到哪里。

python inference.py \
  --data_root "./checkpoints/ditto_trt_Ampere_Plus" \
  --cfg_pkl "./checkpoints/ditto_cfg/v0.4_hubert_cfg_trt.pkl" \
  --audio_path "./example/audio.wav" \
  --source_path "./example/image.png" \
  --output_path "./tmp/result.mp4"

训练在 train 分支

主分支没有完整训练入口。训练代码位于 train 分支，其中入口是 MotionDiT/train.py，数据准备脚本位于 prepare_data，Quick Start 使用 accelerate launch train.py 启动。训练分支 README 提醒：示例训练只用于走通流程，要得到合理效果需要更多高质量数据和更长训练。

git checkout train
cd MotionDiT
accelerate launch train.py \
  --experiment_dir ${EXP_DIR} \
  --experiment_name ${EXP_NAME} \
  --use_sc \
  --use_last_frame \
  --use_last_frame_loss \
  --use_emo \
  --use_eye_open \
  --use_eye_ball \
  --audio_feat_dim 1103 \
  --motion_feat_dim 265

主分支最重要的不是单个模型定义，而是 inference.py、stream_pipeline_offline.py / stream_pipeline_online.py 和 core/atomic_components 下的一组原子组件。它们共同把“音频驱动头像”拆成多阶段队列流水线。

flowchart TD
  User["用户输入
source image/video + audio"] --> CLI["inference.py
命令行入口"]
  CLI --> SDK["StreamSDK
推理编排"]
  SDK --> CFG["parse_cfg
cfg_pkl + data_root"]
  CFG --> Loader["load_model
ONNX / TensorRT / PyTorch"]
  SDK --> Source["Source2Info / AvatarRegistrar
人脸裁剪、关键点、appearance feature"]
  SDK --> Audio["Wav2Feat
HuBERT 音频特征"]
  Source --> Cond["ConditionHandler
source canonical + audio + emotion + eye"]
  Audio --> Cond
  Cond --> A2M["Audio2Motion
调用 LMDM"]
  A2M --> Stitch["MotionStitch
运动缝合与控制"]
  Stitch --> Warp["WarpF3D
3D feature warping"]
  Warp --> Decode["DecodeF3D
图像解码"]
  Decode --> Putback["PutBack
回贴到原图"]
  Putback --> Writer["VideoWriter + ffmpeg
输出 mp4"]

inference.py 是一个很薄的入口：它解析命令行参数，创建 StreamSDK，调用 run。真正的工程复杂度在 StreamSDK.setup 和各个 worker 中。

inference.py
  -> StreamSDK(cfg_pkl, data_root)
  -> SDK.setup(source_path, output_path)
  -> librosa.load(audio_path, sr=16000)
  -> Wav2Feat.wav2feat(audio)
  -> audio2motion_queue.put(audio_feature)
  -> 多线程 worker pipeline
  -> ffmpeg 合成临时视频与原音频

入口源码：run 如何把音频送进流水线

这段是真实入口代码。它先用 SDK.setup 注册 source，再把音频固定重采样到 16 kHz；离线模式下，HuBERT 特征会被放入 audio2motion_queue，后续 worker 从队列继续消费。

inference.py

run

def run(SDK: StreamSDK, audio_path: str, source_path: str, output_path: str, more_kwargs: str | dict = {}):

    if isinstance(more_kwargs, str):
        more_kwargs = load_pkl(more_kwargs)
    setup_kwargs = more_kwargs.get("setup_kwargs", {})
    run_kwargs = more_kwargs.get("run_kwargs", {})

    SDK.setup(source_path, output_path, **setup_kwargs)

    audio, sr = librosa.core.load(audio_path, sr=16000)
    num_f = math.ceil(len(audio) / 16000 * 25)

    fade_in = run_kwargs.get("fade_in", -1)
    fade_out = run_kwargs.get("fade_out", -1)
    ctrl_info = run_kwargs.get("ctrl_info", {})
    SDK.setup_Nd(N_d=num_f, fade_in=fade_in, fade_out=fade_out, ctrl_info=ctrl_info)

    online_mode = SDK.online_mode
    if online_mode:
        chunksize = run_kwargs.get("chunksize", (3, 5, 2))
        audio = np.concatenate([np.zeros((chunksize[0] * 640,), dtype=np.float32), audio], 0)
        split_len = int(sum(chunksize) * 0.04 * 16000) + 80  # 6480
        for i in range(0, len(audio), chunksize[1] * 640):
            audio_chunk = audio[i:i + split_len]
            if len(audio_chunk) < split_len:
                audio_chunk = np.pad(audio_chunk, (0, split_len - len(audio_chunk)), mode="constant")
            SDK.run_chunk(audio_chunk, chunksize)
    else:
        aud_feat = SDK.wav2feat.wav2feat(audio)
        SDK.audio2motion_queue.put(aud_feat)
    SDK.close()

    cmd = f'ffmpeg -loglevel error -y -i "{SDK.tmp_output_path}" -i "{audio_path}" -map 0:v -map 1:a -c:v copy -c:a aac "{output_path}"'
    print(cmd)
    os.system(cmd)

sequenceDiagram
  participant CLI as inference.py
  participant SDK as StreamSDK
  participant A2M as Audio2Motion worker
  participant Stitch as MotionStitch worker
  participant Render as Warp/Decode/PutBack workers
  participant Writer as Writer/ffmpeg
  CLI->>SDK: "setup(source_path, output_path)"
  CLI->>SDK: "run(audio_path)"
  SDK->>A2M: "audio feature queue"
  A2M->>Stitch: "motion sequence"
  Stitch->>Render: "stitched keypoints"
  Render->>Writer: "frame images"
  Writer-->>CLI: "result.mp4"

Algorithm: Ditto offline inference
Input: source_path, audio_path, cfg_pkl, data_root
1. Parse cfg_pkl and bind every model path to data_root.
2. Register source image/video: crop face, extract keypoints and 3D feature.
3. Convert waveform to HuBERT audio feature.
4. Feed audio feature into audio2motion queue.
5. LMDM samples motion sequence in motion space.
6. MotionStitch mixes source motion, driving motion, gaze and pose controls.
7. Warp 3D feature, decode crop image, put crop back to original canvas.
8. Write temporary video and mux original audio by ffmpeg.
Output: result.mp4

Ditto 的关键不是直接在像素空间扩散，而是在 motion 表示上做 diffusion。推理侧的核心路径是 core/atomic_components/audio2motion.py 调用 core/models/lmdm.py，再进入 core/models/modules/LMDM.py 和 core/models/modules/lmdm_modules/model.py。

flowchart LR
  X["noisy motion x_t"] --> Decoder["MotionDecoder"]
  Frame["cond_frame"] --> Decoder
  Audio["audio condition"] --> Tokens["condition tokens"]
  EmoEye["emotion / eye / source canonical"] --> Tokens
  T["timestep embedding"] --> Decoder
  Tokens --> Decoder
  Decoder --> X0["predicted x_start"]
  X0 --> DDIM["DDIM update"]
  DDIM --> Next["x_t_minus_1"]

MotionDecoder 会把当前 noisy motion、条件帧、音频条件以及 timestep embedding 组合起来。源码中的 guided_forward 是 classifier-free guidance 风格：先算无条件输出，再算有条件输出，然后用 guidance_weight 放大二者差值。

核心源码：guidance 与 DDIM 采样

guided_forward 不是伪概念，而是源码里直接实现的 classifier-free guidance：同一批 noisy motion 分别跑无条件和有条件分支，再用 guidance_weight 放大条件分支带来的差异。

core/models/modules/lmdm_modules/model.py

MotionDecoder.guided_forward / forward

    def guided_forward(self, x, cond_frame, cond_embed, times, guidance_weight):
        unc = self.forward(x, cond_frame, cond_embed, times, cond_drop_prob=1)
        conditioned = self.forward(x, cond_frame, cond_embed, times, cond_drop_prob=0)

        return unc + (conditioned - unc) * guidance_weight

    def forward(
        self, x: Tensor, cond_frame: Tensor, cond_embed: Tensor, times: Tensor, cond_drop_prob: float = 0.0
    ):
        batch_size, device = x.shape[0], x.device

        # concat last frame, project to latent space
        # cond_frame: [b, dim] | [b, n, dim+1]
        if self.multi_cond_frame:
            # [b, n, dim+1] (+1 mask)
            x = torch.cat([x, cond_frame], dim=-1)
        else:
            # [b, dim]
            x = torch.cat([x, cond_frame.unsqueeze(1).repeat(1, x.shape[1], 1)], dim=-1)
        x = self.input_projection(x)
        # add the positional embeddings of the input sequence to provide temporal information
        x = self.abs_pos_encoding(x)

        # create audio conditional embedding with conditional dropout
        keep_mask = prob_mask_like((batch_size,), 1 - cond_drop_prob, device=device)
        keep_mask_embed = rearrange(keep_mask, "b -> b 1 1")
        keep_mask_hidden = rearrange(keep_mask, "b -> b 1")

        cond_tokens = self.cond_projection(cond_embed)
        # encode tokens
        cond_tokens = self.abs_pos_encoding(cond_tokens)
        cond_tokens = self.cond_encoder(cond_tokens)

        null_cond_embed = self.null_cond_embed.to(cond_tokens.dtype)
        cond_tokens = torch.where(keep_mask_embed, cond_tokens, null_cond_embed)

ddim_sample 则负责从高斯噪声开始迭代更新 motion。每一步先预测 x_start 与噪声，再按 DDIM 公式更新到下一个时间步。

core/models/modules/LMDM.py

MotionDiffusion.ddim_sample

    @torch.no_grad()
    def ddim_sample(self, kp_cond, aud_cond, sampling_timesteps):
        self.setup(sampling_timesteps)

        cond_frame = kp_cond
        cond = aud_cond

        shape = (1, self.seq_frames, self.motion_feat_dim)
        x = torch.randn(shape, device=self.device)

        x_start = None
        i = 0
        for _, time_next in self.time_pairs:
            time_cond = self.time_cond_list[i]
            pred_noise, x_start = self.model_predictions(x, cond_frame, cond, time_cond)
            if time_next < 0:
                x = x_start
                continue

            alpha_next_sqrt = self.alpha_next_sqrt_list[i]
            c = self.c_list[i]
            sigma = self.sigma_list[i]
            noise = self.noise_list[i]
            x = x_start * alpha_next_sqrt + c * pred_noise + sigma * noise

            i += 1
        return x  # pred_kp_seq

训练分支的主入口是 MotionDiT/train.py。它通过 tyro 解析训练参数，创建 Trainer，再由 Trainer.train_loop 执行训练。关键路径包括 MotionDiT/src/trainers/trainer.py、MotionDiT/src/datasets/s2_dataset_v2.py、MotionDiT/src/models/LMDM.py 和 MotionDiT/src/models/modules/diffusion.py。

flowchart TD
  TrainPy["MotionDiT/train.py"] --> Trainer["Trainer"]
  Trainer --> Dataset["Stage2Dataset"]
  Dataset --> Batch["kp_seq / kp_cond / aud_cond"]
  Trainer --> LMDMTrain["LMDM.diffusion"]
  Batch --> LMDMTrain
  LMDMTrain --> Loss["MotionDiffusion.p_losses"]
  Loss --> Backward["loss backward + optimizer step"]

Stage2Dataset 会加载 motion、audio、emotion、eye 等预处理特征，切成固定长度片段，返回 kp_seq、kp_cond 和 aud_cond。p_losses 不只计算 position loss，还支持 velocity、acceleration、last-frame loss 和 regularization loss。

core/utils/load_model.py 通过文件后缀选择 ONNX Runtime、TensorRT 或 PyTorch backend。这让上层 atomic component 不必关心底层模型格式，也解释了为什么 README 可以提供 TensorRT、ONNX、PyTorch 三类权重路径。

模型加载源码：用后缀切换推理后端

这里是可替换 backend 的关键：.onnx 走 ONNX Runtime，.engine / .trt 走 TensorRT，.pt / .pth 才实例化 PyTorch module。

core/utils/load_model.py

load_model

def load_model(model_path: str, device: str = "cuda", **kwargs):
    if kwargs.get("force_ori_type", False):
        # for hubert, landmark, retinaface, mediapipe
        model = load_force_ori_type(model_path, device, **kwargs)
        return model, "ori"

    if model_path.endswith(".onnx"):
        # onnx
        import onnxruntime

        if device == "cuda":
            providers = ["CUDAExecutionProvider", "CPUExecutionProvider"]
        else:
            providers = ["CPUExecutionProvider"]
        model = onnxruntime.InferenceSession(model_path, providers=providers)
        return model, "onnx"

    elif model_path.endswith(".engine") or model_path.endswith(".trt"):
        # tensorRT
        from .tensorrt_utils import TRTWrapper

        model = TRTWrapper(model_path)
        return model, "tensorrt"

    elif model_path.endswith(".pt") or model_path.endswith(".pth"):
        # pytorch
        model = create_model(model_path, device, **kwargs)
        return model, "pytorch"

运动缝合源码：source 身份与 driving motion 如何混合

MotionStitch 是控制感最强的一段代码：它先按 use_d_keys 混合 source 与 driving motion，再处理眼睛、VAD、姿态偏移和 fade，最后把 source / driving motion 都变成 keypoint，并可选调用 stitching network 修正。

core/atomic_components/motion_stitch.py

MotionStitch.__call__

    def __call__(self, x_s_info, x_d_info, **kwargs):
        # return x_s, x_d

        kwargs = self._merge_kwargs(self.overall_ctrl_info, kwargs)

        if self.scale_ratio is None:
            self.scale_b = x_s_info['scale'].item()
            self.scale_ratio = self.scale_a / self.scale_b
            self._set_scale_ratio(self.scale_ratio)

        if self.relative_d and self.d0 is None:
            self.d0 = copy.deepcopy(x_d_info)

        x_d_info = _mix_s_d_info(
            x_s_info,
            x_d_info,
            self.use_d_keys,
            self.d0,
        )

        delta_eye = 0
        if self.drive_eye and self.delta_eye_arr is not None:
            delta_eye = self.delta_eye_arr[
                self.delta_eye_idx_list[self.idx % len(self.delta_eye_idx_list)]
            ][None]
        x_d_info = _fix_exp_for_x_d_info_v2(
            x_d_info,
            x_s_info,
            delta_eye,
            self.fix_exp_a1,
            self.fix_exp_a2,
            self.fix_exp_a3,
        )

        if kwargs.get("vad_alpha", 1) < 1:
            x_d_info = ctrl_vad(x_d_info, x_s_info, kwargs.get("vad_alpha", 1))

        x_d_info = ctrl_motion(x_d_info, **kwargs)

        if self.fade_type == "d0" and self.fade_dst is None:
            self.fade_dst = copy.deepcopy(x_d_info)

        # fade
        if "fade_alpha" in kwargs and self.fade_type in ["d0", "s"]:
            fade_alpha = kwargs["fade_alpha"]
            fade_keys = kwargs.get("fade_out_keys", self.fade_out_keys)
            if self.fade_type == "d0":
                fade_dst = self.fade_dst
            elif self.fade_type == "s":
                if self.fade_dst is not None:
                    fade_dst = self.fade_dst
                else:
                    fade_dst = copy.deepcopy(x_s_info)
                    if self.is_image_flag:
                        self.fade_dst = fade_dst
            x_d_info = fade(x_d_info, fade_dst, fade_alpha, fade_keys)

        if self.drive_eye:
            if self.pose_s is None:
                yaw_s = bin66_to_degree(x_s_info['yaw']).item()
                pitch_s = bin66_to_degree(x_s_info['pitch']).item()
                self.pose_s = [yaw_s, pitch_s]
            x_d_info = _fix_gaze(self.pose_s, x_d_info)

        if self.x_s is not None:
            x_s = self.x_s
        else:
            x_s = transform_keypoint(x_s_info)
            if self.is_image_flag:
                self.x_s = x_s

        x_d = transform_keypoint(x_d_info)

        if self.flag_stitching:
            x_d = self.stitch_net(x_s, x_d)

从源码结构看，实时性并不是单靠一个模型很快，而是来自“分阶段队列 + worker 并行 + 可替换推理后端”的组合。
